BBE Acousti-Max 386-Acoustic Instrument Preamp Pedal

BBE Acoustimax 386-Acoustic Instrument Preamp Pedal Overview :

In the years since BBE last offered its award-winning 386 acoustic preamp,BBE's design and engineering teams studied the recording and sound reinforcement needs of serious acoustic players.
The result is all-analog Acoustimax,a stompbox-style acoustic preamp which raises the bar for amplified acoustic instrument sound quality.

Applications

• Recording studio
• Live concerts

Features :

• Three band, recording-console quality eq with a sweepable mid-range band
• Low-frequency notch filter
• Phase reversal
• Ground lift
• Line level out
• Dedicated tuner out
• TRS effects loop
• Pre/post switchable-balanced DI output with pad
• Hardwire bypass
• Non-slip rubber bottom
• 12v power supply included

Specifications :

• Frequency response
• 50Hz to 20kHz
• Treble ±12dB @ 10kHz
• Mid ±12dB @ 400kHz to 2.5kHz
• Bass ±12dB @ 60kHz
• Notch 0 to -12dB @ 70Hz to 250kHzBBE
• Lo Contour: +15dB @ 50Hz
• Process: +15dB @ 10kHzMaximum output
• +10dBu @ instrument jack

Noise

• Instrument jack: -98dBv (unity gain)
• Line out: -88dBv (+10dB gain)
• Total harmonic distortion (THD)
• 0.05% @ 1kHz

Impedances

• Input: 2.2M Ohm
• Tuner out: 2k Ohm
• Line out: 1k Ohm
• Instrument out: 2k Ohm
• XLR out: 600 Ohm (* 0dBu=0.775Vrms)
• Power requirements
• DC inlet +12 VAC min. 200ma
• Designed and Engineered in USA

Made in China
